Kamasonic PA-80F Amplifier

Product Details:

• Model: PA-80F

• Brand: Kamasonic

• Output Power: 80W x 2 (at 8Ω)

• Frequency Response: 60Hz – 20kHz (±2dB)

• Input Sensitivity:

  • Microphone: 5–100mV / 1kΩ

  • Line: 50mV / 47kΩ

• Output Impedance: 4Ω – 16Ω

• Output Voltage: 70V / 100V

• Power Supply: AC 210V–230V, 50Hz

• Material: Aluminum alloy and plastic

• Cooling System: Temperature-controlled cooling fan

• Dimensions: [Not specified]

• Weight: [Not specified]

Features:

• Audio Inputs:

  • 2 Microphone Inputs

  • 1 Auxiliary Input

  • 1 Auxiliary Output

• Playback Options:

  • MP3 Functionality

  • USB and SD Card Inputs

  • FM Radio

  • Bluetooth Connectivity

• Controls:

  • Separate Treble, Mid-range, and Bass Controls

  • Two-channel Audio and Video Input Selection

• Additional Features:

  • Temperature-controlled Cooling Fan

  • Durable Aluminum Alloy and Plastic Construction

Best For:

• Public Address Systems in Schools, Restaurants, Shops, Stations, and Hotels

• Small to Medium-sized Venues

• Events Requiring Clear Audio Output

How to Use:

1. Power On: Connect the amplifier to a 210V–230V power source and switch it on.

2. Connect Inputs: Plug in microphones or auxiliary devices into the respective input ports.

3. Playback: Use USB, SD card, FM radio, or Bluetooth to play audio content.

4. Adjust Settings: Utilize the treble, mid-range, and bass controls to fine-tune the audio output.

5. Monitor Cooling: The built-in temperature-controlled fan ensures optimal operating temperature.
